Quantum Edge 3 Stretto Powerchair

Product Information

• Description

  The Quantum Edge 3 Stretto Electric Wheelchair is a mid-wheel drive powerchair that features an ultra-narrow base width for outstanding manoeuvrability, as well as SRS (Smooth Ride Suspension), making it the perfect indoor/outdoor electric wheelchair.

  An ultra-narrow base width of just 52cm combined with mid-wheel drive allows the Quantum Edge 3 Stretto Electric Wheelchair to turn on the spot for superb manoeuvrability indoors.  Its performance outdoors is also impressive, with optional 6 mph motors and long-range 62 Ah batteries.

  • SRS (Smooth Ride Suspension) is a superior automotive-grade electric wheelchair power suspension developed after two years of research and consumer feedback. SRS provides a smooth comfortable ride and advanced stability.

  • LED lights come as standard, mounted to the fender above the drive tyres on each side, ensuring that you can see and be seen.

  • Choose from a range of control options, from the standard NE+ system to the Q-Logic 3 Advanced Drive Control System, an adaptable control system that includes wireless Bluetooth programming and device access, in-built USB charger and attendant control options.

  Contoured Seating

  • A basic Captain’s seating system available in a limited range of sizes, a simple option where special positioning isn’t needed. It features adjustable seat depth, height adjustable arms and a reclining back which folds flat, making it perfect for car boot hoisting.

  TB Flex Seating

  • TB Flex is an entry-level prescriptive seating system which is fully adjustable to suit your needs. It provides up to 30° of tilt, 254 mm (10 inches) of lift, can recline 95°-125°, and can tilt/recline up to 125°.

  TRU-Balance® 3 Power Positioning System

  • TRU-Balance® 3 Power Positioning System features quick adjustment with minimum fuss. An innovative design that maximises functional independence while providing an appealing look and feel. iLevel® seat lift is the stand-out feature on this seating system, allowing you to drive at 3.5 mph with the seat fully elevated by 12 inches. A full range of power options includes 175° of powered recline, giving you a lie-flat position when combined with powered elevating leg rests.







  Why we recommend

  The Quantum Edge 3 Stretto Electric Wheelchair is an ideal choice if you’re looking for the best power wheelchair for confined indoor spaces, with its ultra-narrow mid-wheel base, or if you need a fully modular powerchair for more advanced postural needs but don’t need high-end outdoor performance. It’s also ideal if you need an electric wheelchair that will cater for changing needs in the future. If width is not important to you, or you’ll primarily be using your electric wheelchair outdoors, we recommend looking at the standard Quantum Edge 3 or the Invacare TDX – contact us for more info.

• Dimensions & Technical Info

  Length	826 mm / 32.5 inches without front riggings
  Width	530 mm / 20.75 inches with 12.4 inch drive wheels, 552 mm / 21.75 inches with 14 inch drive wheels
  Seat height	TRU-Balance® 3 Static Seat 5: 16 – 18 inch TRU-Balance® 3 Power Tilt 5: 17.5 – 19.5 inch TRU-Balance® 3 Tilt & iLevel® 5: 17.5 – 19.5 inch TRU-Balance® Flex Seating: 16.5 – 18.25 inch
  Seat width/depth	TRU-Balance® 3 Static Seat: Width: 10 – 20 inches / Depth: 10 – 20 inches TRU-Balance® 3 Power Tilt Width: 12 – 20 inches / Depth: 12 – 20 inches TRU-Balance® 3 Tilt and iLevel® Width: 12 – 20 inches / Depth: 12 – 20 inches TRU-Balance® Flex Seating Width: 15 – 20 inches / Depth: 15 – 20 inches
  Maximum speed	4 mph (6 mph optional)
  Batteries	40 Ah (TB Flex Seating), 62 Ah (TB3 Seating)
  Maximum range	Up to 15.9 miles (25.6 km) with 40 Ah batteries Up to 20.3 miles (32.7 km) with 55 Ah batteries
  Turning radius	533 mm / 21 inches
  Safe working load	136 kg / 21 stone
  Crash Teste	Yes

• Documentation

  Edge 3 Stretto Brochure

  Edge 3 Stretto Order Form – Contoured Seating

  Edge 3 Stretto Order Form – TB Flex Seating

  Edge 3 Stretto Order Form – TB3 Seating

  Edge 3 Stretto Order Form – TB4 Seating

  Edge 3 Stretto User Manual
